连接器型号:20351-112R-37
适用线材:OD1.37mm Coaxial Cable
线材颜色:Black，White
Key Features:
1. Receptacle P/N:20279-001E-01
2. Mating Height:2.5mm MAX
3. Applicable Technology :IEEE802.11 a/b/g/n, UWB, WiMAX, iBurst,
Zigbee,Bluetooth Wireless and MIMO
Specifications:
1. Frequency Range :DC up to 6GHz
2. Characteristic Impedance :50 ohm ( Nominal )
3. Temperature :-40°Cto +90°C
4. Rated Voltage :AC 60V
5. Contact Resistance :20m ohm MAX. ( Signal ) and 10m ohm MAX. ( Ground )
6. Withstand Voltage :AC 200V
7. Insulation Resistance :500M ohm MIN. / DC 100V
8. VSWR: 1.30 Max (DC 1GHz-3GHz)
1.50 Max (DC 3GHz-6GHz)
9.Unmateing Force:Initial 5N Min
After 30 cycles 3N Min
10.Crimp Strength: 20351-112R-37 25N MIN
